Exterior design of STIHL guide bars are subject to change. Technical specifications remain the same.

"/> here.


Exterior design of STIHL guide bars are subject to change. Technical specifications remain the same.

"/>
£797.20
Prices include 20% VAT.
Select option

Technical details

Bar length35-45 cm
Bar length14-18 "
Displacement50.2 cm³
Power output2.6/3.5 kW/HP
Weight5.6 kg 1)

Features

The pictures shown are sample photos. The actual appearance of the equipment features and their specific attachment to the product may differ from the pictorial representations, but will have the same functionality.

HIGHLY POWER-EFFICIENT. With the STIHL 2-MIX engine, you can reduce exhaust emissions and fuel consumption, and therefore operating costs. This 2-stroke engine is low-maintenance and uses fuel efficiently even at high power levels. Use a mixture of petrol and engine oil as fuel. The STIHL 2-MIX engine complies with the strict EU Stage V emissions directive.
STIHL 2-MIX engine
FOR SIMPLE AND SECURE RE-TENSIONING. Side-mounted chain tensioning allows for protected, easy and quick chain tensioning and replacement. The tensioning screw is inserted laterally through the sprocket cover.
SIDE-MOUNTED CHAIN TENSIONING
EXTENDED FILTER SERVICE LIFE. Pre-separation routing removes coarse, larger particles from the airstream before they can reach the actual filter. The HD2 filter keeps even fine dust away from the engine, ensuring a long engine service life, long cleaning intervals and easy maintenance of your chainsaw. When we refer to a long-life air filter system in chainsaws, this exclusively describes models that have pre-separation routing and an HD2 filter. With this system, you benefit from a significantly longer filter service life compared to conventional air filter systems.
Pre-separation air filtration system
FOR MORE PLEASANT WORK. Vibrations can occur when you put your tools through their paces, and these are particularly noticeable in the grip area. The buffer and spring elements of the STIHL anti-vibration system reduce the transmission of engine vibrations to the handle area and therefore to your body. The result is that your tool is more comfortable to hold and your work is much less tiring.
STIHL anti-vibration system
Four overflow channels swirl the fuel-air mix before ignition, allowing for optimum combustion and highly efficient performance. The result is lower fuel consumption and high torque across a broad rpm range.
Advanced combustion technology
By changing the chain saw from summer to winter operation, the intake air is pre-heated over the engine fins. This ensures that the carburettor does not ice up and you can continue working in freezing temperatures.
CARBURETTOR HEATING (V)
QUICK AND EASY TO USE. With tool-free fuel cap, you can open and close oil and fuel tanks in just a few simple steps, thanks to a bayonet closure.
TOOL-FREE FUEL CAP FOR OIL AND FUEL TANKS
SIMPLIFIED OPERATION. Only one start position is required on the combi lever. Thanks to the stop function, once the machine is turned off the control lever immediately moves back into the operating position. This allows a warm machine to be restarted immediately.
COMBI LEVER WITH STOP FUNCTION
